Quick start

With the radio off, check that the correct battery and antenna are fitted. Charge using the authorized equipment and the instructions in the matching user guide.
Turn the On/Off/Volume Control knob clockwise until it clicks. Use the same knob to adjust listening volume.
Select the channel assigned by your radio administrator using the channel controls for your CP100d version. Check the matching manual below before changing zones or programmable buttons.
Press and hold PTT. Wait for the Talk Permit Tone if enabled, speak clearly into the microphone, then release PTT to listen.

Source: Motorola CP100d Limited Keypad user guide. See Getting Started; Radio Controls; Calls.

Programming and fleet setup

Identify the exact model and selected configuration. If you are expanding a fleet, send the current model numbers and programming details to our team so compatibility can be checked before you order.

Use the manual for the exact CP100d faceplate: full keypad, limited keypad or non-display. Provide the existing fleet channel plan and desired button functions to your programmer; the presence of a display does not establish radio-to-radio compatibility.

Ask the Canadian team about setup

Documents

Troubleshooting

The CP100d does not power on

Check the battery charge, attachment and latch. Contact support if a charged, properly attached battery does not resolve the problem.

The first words of a transmission are missing

After pressing PTT, wait until the Talk Permit Tone finishes if that tone is enabled, then speak.

A continuous prohibit tone sounds

Release PTT. Confirm the selected channel and report the tone and circumstances to your radio administrator before trying again.

Frequently asked questions

Which manual applies to the Motorola CP100d Limited Keypad?

Use the Motorola CP100d Limited Keypad user guide in Documents below. Full-keypad, limited-keypad and non-display CP100d radios have different controls.

When should I start speaking on a CP100d?

Press and hold PTT, then wait for the Talk Permit Tone to finish if it is enabled. Speak clearly and release PTT to listen.

What should I check if my CP100d will not power on?

Check that the battery is charged and correctly attached. If the CP100d still does not turn on, contact the Canadian support team with the exact model and battery part number.

Compatible accessories

Use the accessories linked from the Canadian product page. Confirm the radio model, connector and battery or charger part number before adding equipment to an existing system.
