Motorola DTR700 Manuals and Support

Find Motorola DTR700 documentation, setup guidance and the Canadian buying page in one place.

Shop Motorola DTR700 in Canada

What do you need help with?

Start setup →Configure the radio →Find a document →Fix a problem →

Quick start

With the radio off, check that the correct battery and antenna are fitted. Charge using the authorized equipment and the instructions in the matching user guide.
Hold the Power button until the radio vibrates and the Motorola logo appears. Adjust audio with the + and − volume buttons.
Choose the team channel and confirm the fleet Profile ID with your radio administrator before the first group test.
Hold PTT and wait for the Talk Permit Tone before speaking into the microphone. Release PTT to listen.

Source: Motorola DTR700 user guide. See 18–26, 32–38, 51–53.

Programming and fleet setup

Identify the exact model and selected configuration. If you are expanding a fleet, send the current model numbers and programming details to our team so compatibility can be checked before you order.

DTR group communication depends on the configured Profile ID as well as the channel. Record your existing group configuration before adding radios; do not reset the fleet to a generic default as a troubleshooting shortcut.

Ask the Canadian team about setup

Documents

Troubleshooting

The DTR700 is silent

Check whether the radio is muted. Press either volume button to restore the previous listening volume.

A continuous tone sounds when PTT is pressed

The DTR700 will not transmit while it is receiving. Wait for the receiving call to finish, then try PTT again.

New DTR700 radios cannot reach the existing group

Confirm the channel and Profile ID with the fleet administrator. Radios in the group need the same Profile ID to communicate.

Frequently asked questions

Why does my DTR700 cut off the beginning of a message?

Wait for the DTR700 Talk Permit Tone before speaking. The tone follows PTT and indicates that the channel is available.

How do I unmute a DTR700?

Press either volume button. The DTR700 restores the volume level used before it was muted.

What must match when adding a DTR700 to a group?

Confirm the group’s configured Profile ID and channel. Motorola states that radios in the group must use the same Profile ID to communicate.

Compatible accessories

Use the accessories linked from the Canadian product page. Confirm the radio model, connector and battery or charger part number before adding equipment to an existing system.
